| Model | MG-03SFXLRS | MG-03SFXLRS/380 | MG-05SFXLRS | MG-06SFXLRS | MG-10SFXLRS | MG-12SFXLRS | MG-15SFXLRS | MG-20SFXLRS | MG-25SFXLRS | ||
| Heating input power | Heating mode | KW | 2.1 | 2.35 | 4.15 | 4.9 | 8.35 | 9.84 | 10.8 | 14.5 | 19.5 |
| Heating capacity | KW | 10.5 | 11.8 | 21.3 | 25.2 | 42.6 | 50.4 | 56.7 | 74.8 | 99.4 | |
| COP | 5.00 | 5.02 | 5.13 | 5.14 | 5.10 | 5.12 | 5.25 | 5.16 | 5.10 | ||
| Cooling input power | Cooling mode | KW | 1.5 | 1.7 | 3 | 3.4 | 6 | 6.8 | 7.7 | 9.9 | 13.2 |
| Cooling capacity | KW | 6.8 | 7.8 | 14 | 16.5 | 28 | 33 | 37.1 | 49.4 | 67 | |
| EER | 4.53 | 4.59 | 4.67 | 4.85 | 4.67 | 4.85 | 4.82 | 4.99 | 5.08 | ||
| Noise | db | 50 | 50 | 50 | 50 | 50 | 55 | 55 | 55 | 55 | |
| Net weight | kg | 90 | 90 | 123 | 133 | 286 | 306 | 358 | 552 | 592 | |
| Refrigerant | R407C | R407C | R407C | R407C | R407C | R407C | R407C | R407C | R407C | ||
| Compressor | Copeland 1pc | Copeland 1pc | Copeland 2pcs | ||||||||
| Protection function | Temperature, time, water flow, antifreeze, current protection | ||||||||||
