Scroll Type Air Cooled Heat Pump Unit adopts a high-efficiency fully enclosed scroll compressor, a high-efficiency shell-and-tube heat exchanger, and a coil heat exchanger. Utilizing R22, R134a, or R407c refrigerants, the energy efficiency rating can reach Level 2, with hot water outlet temperatures up to 75°C. It is widely used in commercial and industrial sites requiring reliable hot water.
| NORMAL TEMPERATURE AIR SOURCE HEAT PUMP | |||||
|---|---|---|---|---|---|
| TYPE | YJR-HP-10p | YJR-HP-12p | YJR-HP-15p | YJR-HP-20p | |
| Heating Capacity | KW | 36 | 48 | 60 | 80 |
| Water Yield | L/H | 773 | 1030 | 1289 | 1715 |
| Power Supply | 3N/400V/50Hz | ||||
| COP | - | 3.94 | 4.5 | 4.39 | 4.39 |
| Compressor Type | Scroll Compressor | ||||
| Refrigerant | R410A | ||||
| Noise | dB(A) | <60 | ≤60 | ≤62 | ≤65 |
Equipped with mature and reliable ZW series scroll ultra-low-temperature compressors. Operates stably within an ambient temperature range of -25°C to 46°C.
Features hydrophilic aluminum fin multi-circuit design with internal threaded copper tubes. Facilitates rapid drainage of condensate to minimize frost buildup.
Coaxial spiral copper tube heat exchanger employs turbulent flow technology to prevent scale formation and increase energy performance.
Features comprehensive protection functions: exhaust, overcurrent, phase sequence, and high/low pressure protection for automated safe operation.
The EVI low-temperature heat pump unit adopts enhanced vapor injection technology. Compared to conventional units, it demonstrates higher energy efficiency in low-temperature environments, achieving a COP of 2.0 even at -25°C.
We are an integrated industrial and trading enterprise specializing in the design, production, and installation of solar and heat pump products. With ISO and CCC certifications, we provide energy-saving intelligent manufacturing solutions serving global clients in over 50 countries, including Europe, the United States, Germany, and Australia.
