Natural Refrigerant R744 Atw Heat Pump, TUV and ERP Certificate

1 / 5

Natural Refrigerant R744 Atw Heat Pump, TUV and ERP Certificate

Customization:	Available
Energy Efficiency Grade:	One
Heat Temperature:	80-90°C

Send Inquiry

Product Description

Basic Info

Model NO.

DR-40ZW

Work Environment

Low-temperature Heat Pump

Heat Source

Air-source

Heating Type

Multi-power Heat

Application

Villa Family, Sauna and Swimming Pool, Hotels, Factory Hospital, Student Apartments, Beauty Salons

Certification

CE, CCC, RoHS

Compressor

Dorin

Control

Carel

Circuit

Inverter

Refrigerant

R744

Specification

40KW

HS Code

8415812000

Product Description

Real CO2 heat pump water heater featuring advanced Inverter technology.
Utilizes CO2 (R744) - the next generation refrigerant: non-flammable, non-toxic, and natural.
Operates efficiently in extreme conditions down to -25ºC with a high COP, eliminating the need for Aux-heaters.
High-performance system capable of reaching water outlet temperatures of 95ºC.
Full Inverter system (compressor and motors) for maximum energy savings.

Advantages of CO2 (R744) Refrigerant

Climate-neutral and environmentally friendly R744 refrigerant.
No environmentally hazardous decomposition products.
Global Warming Potential (GWP) = 1; Ozone Depletion Potential (ODP) = 0.
No complex disposal or recycling requirements.
Long-term cost-efficiency with no availability constraints or specialized taxes.
Safety Group A1: Non-toxic, non-flammable, and thermally stable.

Technical Specifications

INVERTER CO2 (R744) HEAT PUMP SPECIFICATIONS
Model		Unit	7ZW	8ZW	14ZW	25ZW	40ZW	50ZW	75ZW	120ZW
Standard Temp Condition	Heating Capacity	kW	6.8	7.8	13.6	24	40	51	75.5	125.4
	Hot Water Capacity	L/H	129.9	149	259.8	458	764	974	1442	2396
	Power Input	kW	1.51	1.7	3	5.3	9	11.3	16.7	26.6
	COP	W/W	4.5	4.58	4.6	4.5	4.4	4.5	4.5	4.7
Low Temp Condition	Heating Capacity	kW	5.8	7	12.1	20	35	45.6	64	95
	Hot Water Capacity	L/H	97.7	118	203.9	337	590	768	1079	1602
	Power Input	kW	1.47	1.7	3	5	9.4	12	16.8	24.3
	COP	W/W	3.9	4.1	4.1	4	3.7	3.8	3.8	3.9
Max Water Temp		ºC	95
Work Ambient Temp		ºC	-25 to 43
Compressor Type		-	Panasonic				Dorin (Italy)

Frequently Asked Questions

What makes CO2 (R744) a superior refrigerant?

CO2 is a natural refrigerant with a Global Warming Potential (GWP) of 1 and zero Ozone Depletion Potential (ODP). It is non-toxic, non-flammable, and does not require complex recycling processes, making it the most environmentally friendly option for modern heating.

Can the heat pump provide hot water in extremely cold climates?

Yes, this CO2 heat pump is specifically designed for low-temperature environments. It can operate efficiently at ambient temperatures as low as -25ºC while maintaining a high COP without the need for auxiliary electric heaters.

What is the maximum water temperature this system can produce?

The system is capable of producing hot water with an outlet temperature of up to 95ºC, making it suitable for specialized industrial requirements, hotels, and hospitals that need high-temperature sanitation.

How does Inverter technology save energy?

Our system utilizes full Inverter technology for both the compressor and motors. This allows the unit to adjust its power output based on real-time demand rather than running at 100% capacity constantly, resulting in significantly lower electricity consumption.

Is the system safe for indoor or residential use?

Absolutely. CO2 refrigerant is classified under Safety Group A1, meaning it is non-toxic and non-flammable. It is one of the safest refrigerants available for residential villas, apartments, and commercial beauty salons or spas.

What certifications do these units carry?

The units are fully certified with CE, CCC, and RoHS standards, ensuring they meet rigorous international safety, health, and environmental protection requirements.
